Used In Vehicles With External Ballast Resistor. 12 Volt with more than enough power to keep your Vehicle powering on perfectly.
This Coil is used for vehicles with an External Ballast Resistor. If yours is non ballasted then see the coil below this listing.
Fits Most of these Vehicles-
BEDFORD.
1960-80. TJ, TK Series 214, 300, and 250 Chev
Australian market CF Bedfords with Holden red & Blue Motors 173 & 202 c.i.
DODGE
1957-on. V8
1961-on. 6 Cylinder AT4, D5N.
INTERNATIONAL
6 Cylinders using External Resister
V8 Models all.
IF YOU HAVE DOUBT WHICH IS CORRECT COIL DO THIS
Measure Primary Resistance across the Coil (+ and - terminals):Resistor Coil (Ballasted): Resistance measures 1.2 OHMS to 1.8 OHMS. (Requires an external ballast resistor or resistor wire in series to drop operating voltage to ~8V–9V).Standard 12V Coil (Non-Ballasted): Resistance measures 2.8 OHMS to 3.5 OHMS. (Runs directly on 12V without an external resistor).
